Dallnet series O^®: Aluminium weather drips for external walls and balcony edges

The system

Dallnet Drop Water is a system allowing the separation of the run-off water in front, in nose of slab and in nose of balcony.

It protects the facade cladding, thus avoiding unsightly soiling and dripping. It delays the degradation of the structures (spalling, cracks, etc.) and related costs of repairs.

Available in Raw Aluminum, natural anodised aluminum and Danilac lacquered Aluminum RAL colors.

The profiles are available in standard lengths of 3000 mm, drilled in 5 mm diameter every 675 mm (150 mm at the ends).
When working, a clearance of 5 mm must be maintained between the elements.
The use of prefabricated accessories at the factory is essential for the proper functioning of the system:

• Junction parts
• Corner pieces
• Finishing tips

The profile

Dallnet water drop model 50 is factory equipped with a seal bottom. It allows the mastic to maintain its full elasticity durably, absorbing the dilatations and thus avoiding torsional cracks.

The profile prevents dirt and sagging on the facade or on the slab nose and protects the facade cladding at the top. The fixing is done by mechanical fixing and by gluing.

Accessories

Connecting piece

Placed by gluing, it makes it possible to fill the necessary expansion of 3 to 5 mm between 2 lengths.

Tip

The tip prevents lateral sagging.

Example of use

The system includes:

• Standard length profiles of 3000 mm, drilled diameter 5 every 600 mm
• The connecting pieces
• Reentrant or outgoing corner pieces
• The tips

The profile

Dallnet water drop model 45 is adjustable in height and is also used in shut-off liquid seal.

The profile prevents dirt and sagging on the facade or on the slab nose and protects the facade cladding at the top. The fixing is done by mechanical fixing and by gluing.

Accessories

Connecting piece

Placed by gluing, it makes it possible to fill the play of dilation of 3 to 5 mm indispensable between 2 lengths.

Tip

The tip prevents lateral sagging

Example of use

The system includes :

• Standard length profiles of 3000 mm, drilled diameter 5 every 600 mm
• The connecting pieces
• Reentrant or outgoing corner pieces
• The tips

The profile

Dallnet model 45 water drop in the face forms a discharge of water in the face of nose of slab or balcony. It makes it possible to mask the spalling and dirt on the underside. It avoids run-off water from the balconies and lower terraces.
The profile prevents dirt and sagging on the facade or on the slab nose and protects the facade cladding at the top. The fixing is done by mechanical fixing and by gluing.

Accessories

Connecting piece

Placed by gluing, it makes it possible to fill the necessary expansion of 3 to 5 mm between 2 lengths.

Example of use

The system includes :

• Standard length profiles of 3000 mm, drilled diameter 5 every 600 mm
• The connecting pieces
• Reentrant or outgoing corner pieces
• The tips

The profile

Bendable model for use on rounded facades.

Fixnet 40 bendable forms a discrete water discharge on the facade. It bends on site to fit curved parts.
It is available in rough aluminum, to be painted on site, or in Danilac lacquered aluminum, in all RAL colors.
This model has no accessories.

Fixnet 40 is delivered with a drilled hole. Hole spacing: 300 mm.
On request, Fixnet 40 can be delivered without drilling (drilled at the ends in lacquered finish).

NB: for roundings with a diameter of less than 1 m, we recommend non-drilled profiles (drilled at the ends in lacquered finish).

Example of use

Fully bonded with polyurethane adhesive.
If necessary, complete with a suitable mechanical fixing.
